Programmable by the user, simple for the operator
Programmable Label Printing Scales are intended for production teams that need weighing and label printing without rewriting software for every label format. The setup portal lets the user configure fields, PRN template placeholders, serial format, print mode, labels-per-print and automatic threshold. During production, the operator follows guided prompts and prints labels using manual or automatic mode.
Browser based configuration
Open the local setup page, edit settings, upload the PRN template and save. No internet is required for setup.
User programmable fields
Use automatic scale data, manual operator entry and generated serial numbers as required by the label.
Repeatable printing
Saved label settings help keep production labels consistent across batches and operators.
CSV logging on Pro MAX
Successfully printed label records can be downloaded for production traceability.
Models and indicative prices
Choose Basic, Pro or Pro MAX according to the label fields and production logging requirement. All versions are user programmable and easy to set up for label format, copies, threshold and print mode.
Basic
For direct weight, date, time, serial number and simple label printing requirements.
- Manual and automatic printing
- Labels-per-print: 1 to 99
- Configurable automatic threshold
Pro
For applications where the operator must enter product, batch, customer or other label fields.
- User entry fields
- USB QWERTY keyboard entry
- Manual and automatic printing
Pro MAX
For label printing with production traceability and downloadable CSV logging.
- CSV record memory
- Wi-Fi log download
- Best for traceability
Prices are indicative selling prices for the label printing scale electronics/configuration. Taxes, printer, platform/load cell, shipping, installation and application-specific customization are extra as applicable.
Basic, Pro and Pro MAX comparison
All variants retain the primary weight display, guidance LCD, manual/automatic printing, labels-per-print setting and configurable automatic threshold. Pro and Pro MAX add operator entry. Pro MAX adds production data memory and CSV download.
| Capability | Basic | Pro | Pro MAX |
|---|---|---|---|
| Indicative selling price | |||
| Primary LED weight display and guidance LCD | Included | Included | Included |
| Weight, date, time and generated serial fields | Included | Included | Included |
| Manual and automatic label printing | Included | Included | Included |
| Labels-per-print setting | 1 to 99 copies | 1 to 99 copies | 1 to 99 copies |
| Automatic print threshold | Configurable | Configurable | Configurable |
| User entry fields | - | Included | Included |
| USB QWERTY keyboard field entry | - | Included | Included |
| CSV production record memory | - | - | Up to 12,000 records |
| Wi-Fi log download and reset | - | - | Included |
Setup workflow
Design label
Create the label in software suitable for the selected printer and generate a raw PRN file.
Map placeholders
Insert displayed placeholders into the PRN template for weight, date, time, serial and manual fields.
Configure fields
Set field names, entry frequency, serial format, print mode, label copies and automatic threshold.
Print production labels
Restart, enter prompted values, receive stable scale data and print complete labels.
Operation modes and label control
Manual printing
The label is sent only after an operator command. Basic uses a dedicated front-panel print button. Pro and Pro MAX can use keyboard print command after field entry.
Automatic printing
A label is triggered on a new stable-weight event only when the weight is equal to or above the configured automatic threshold. Unstable data and weights below threshold do not print automatically.
Labels per print
Set 1 to 99 identical labels for each manual or automatic print trigger. This is useful for carton, product and internal-copy labelling.
Operator prompts
Pro and Pro MAX can prompt for product, operator, batch, customer or any configured text field at every label or once per power-on.
Printer and PRN requirements
CSV logging on Pro MAX
Pro MAX records data from successfully transmitted labels in downloadable CSV format. The log can include serial number, manually entered fields, weight, time and date. Downloading does not automatically delete records; a confirmed reset is available when the user wants to clear memory.
SERIAL_NO,PRODUCT,OPERATOR,WEIGHT,TIME,DATE 260724/001,PRODUCT A,OPERATOR 1,12.500,15:42:00,24-07-26 260724/002,PRODUCT B,OPERATOR 1,08.250,15:46:12,24-07-26
Logging safeguards
- Record count and free memory visible in setup page
- Advance capacity warning near memory limit
- Manual CSV download over local Wi-Fi
- Confirmed delete function
- Rollover warning when older records are replaced
Product data and integration
Applications
Packing and dispatch
Print carton labels with weight, product, batch and serial details.
Batch production
Use configurable fields for product, operator, customer and batch information.
Warehouse labelling
Generate repeatable labels without a PC at every station.
Traceability systems
Use Pro MAX logging to keep CSV records of completed label prints.
